CAMERON AAP3798102-001 30通用显示压缩机控制模块使用通用接线板或接线板将接线板安装在控制外壳内，并将屏蔽电缆从接线板连接到模块接线板端子上的每个输入电路。Y将每根电缆的屏蔽连接到接线板旁边的金属面板。不要在模块端连接屏蔽(在电缆模块端切断屏蔽并用热缩管绝缘)。Y用屏蔽电缆将现场设备连接到端子板，仅在设备端接地屏蔽(在电缆的端子板端切断屏蔽并用热缩管绝缘)。此外，应尽可能缩短端子板和设备端的外露(屏蔽外部)引线的长度。直接方法Y将屏蔽电缆从现场设备(传感器、电位计等)直接连接到模块。Y将导体连接到模块端子板上的适用螺钉上。将现场设备端的屏蔽接地，使最小数量的导体暴露在噪声环境中。不要在模块端连接屏蔽(切断电缆模块端的屏蔽并用热缩管绝缘)。CAMERON AAP3798102-00130TBQC不推荐用于模拟模块由于电缆屏蔽要求，端子板快速连接(TBQC)组件不建议用于模拟模块
AAP3798102-00130
AAP3798102-00130
CAMERON AAP3798102-001 30 Universal Display Compressor Control Module uses a universal terminal block or terminal block to install the terminal block inside the control enclosure and connect shielded cables from the terminal block to each input circuit on the module terminal block terminals. Y Connect the shielding of each cable to the metal panel next to the wiring board. Do not connect a shield at the module end (cut the shield at the cable module end and insulate with a heat shrink tube). Y uses shielded cables to connect the on-site equipment to the terminal board, grounding the shield only at the equipment end (cutting the shield at the terminal board end of the cable and insulating it with heat shrink tubing). In addition, the length of exposed (shielded external) leads on terminal boards and equipment ends should be minimized as much as possible. Direct method Y connects shielded cables directly from field devices (sensors, potentiometers, etc.) to the module. Y Connect the conductor to the applicable screw on the module terminal board. Ground the shielding of the on-site equipment end to expose the minimum number of conductors to a noisy environment. Do not connect shielding at the module end (cut off the shielding at the module end of the cable and insulate it with a heat shrink tube). CAMERON AAP3798102-00130TBQC is not recommended for analog modules. Due to cable shielding requirements, Terminal Board Quick Connect (TBQC) components are not recommended for analog modules
AAP3798102-00130
AAP3798102-00130
