BNC-2110（零件号：777763-01）是一种屏蔽、DIN导轨、台式安装接线板。该接线板提供68针、内螺纹SCSI至1针、内孔BNC（数量为15）、30针、内弹簧端子连接。NI BNC-2110设计用于与各种National Instruments多功能I/O和模拟输出设备配合使用。BNC-2110有助于简化模拟信号以及一些数字信号与DAQ设备的连接。有了这个接线板，您可以实现更好的测量完整性，因为BNC-2110带有屏蔽外壳。桌面安装和DIN导轨安装配置可以使用此屏蔽接线板。该设备使用NI DAQmx驱动程序软件运行，该软件与LabVIEW、LabWindows/CVI或Measurement Studio等软件包兼容。设备硬件可以使用Measurement&Automation Explorer（MAX）工具进行配置。
BNC-2110
NI BNC-2110可与100引脚或68引脚E/M/S系列或68引脚NI-672x、NI-671x和NI-673x模拟输出（AO系列）DAQ设备一起使用。National Instruments BNC-2110广泛用于要求苛刻的生产、测试和实验室环境。BNC-2110仅用于差分模拟输入信号。使用此接线板，您可以通过将BNC连接器下方的相应开关移动到FS位置来测量浮动信号。此外，该接线板还可以测量接地参考信号。对于接地参考信号，将正在使用的AI通道的BNC连接器下方的开关移动到GS位置。该设备配备了15个BNC连接器，并具有一个68针SCSI公头I/O连接器前面板BNC连接器可用于将AI＜0…7＞信号连接到E/M/S系列DAQ设备。用户1和用户2 BNC连接器使用户能够使用BNC连接器来接收用户选择的数字或定时I/O信号。USER 1和USER 2 BNC连接器连接至USER 1与USER 2弹簧端子。
BNC-2110
The NI BNC-2110 can be used with 100 pin or 68 pin E/M/S series or 68 pin NI-672x, NI-671x, and NI-673x analog output (AO series) DAQ devices. National Instruments BNC-2110 is widely used in demanding production, testing, and laboratory environments. BNC-2110 is only used for differential analog input signals. Using this wiring board, you can measure the float signal by moving the corresponding switch below the BNC connector to the FS position. In addition, the terminal block can also measure ground reference signals. For the ground reference signal, move the switch below the BNC connector of the AI channel being used to the GS position. The device is equipped with 15 BNC connectors and has a 68-pin SCSI male I/O connector. The front panel BNC connector can be used to connect AI<0… 7>signals to the E/M/S series DAQ device. User 1 and User 2 BNC connectors enable users to use BNC connectors to receive digital or timed I/O signals selected by the user. Connect the USER 1 and USER 2 BNC connectors to the USER 1 and USER 2 spring terminals.
BNC-2110
