15插槽卡文件接受构成HPMM的两个HPMM卡和UCN接口模块，并容纳多达13个IOP卡。卡槽从最左边开始编号为1到15。高性能通信/控制和高性能I/O链路卡占用插槽1和2,而HPM UCN接口模块安装在其50针连接器的插槽1下方。插槽3至15可以容纳IOP卡。IOP卡插槽使用数字I/O链路接口地址3到15和二进制/O链路接口地址2到14。当安装了HPMM卡时，卡文件被指定为1 5槽HPMM卡文件。
CC-PAIM01
CC-PAIM01
The 15 slot card file accepts two HPMM cards and UCN interface modules that make up the HPMM, and accommodates up to 13 IOP cards. The card slots are numbered from 1 to 15 starting from the far left. The high-performance communication/control and high-performance I/O link cards occupy slots 1 and 2, while the HPM UCN interface module is installed below slot 1 of its 50 pin connector. Slots 3 to 15 can accommodate IOP cards. The IOP card slot uses digital I/O link interface addresses 3-15 and binary I/O link interface addresses 2-14. When an HPMM card is installed, the card file is specified as a 15 slot HPMM card file.
