CP451-50 I/O 模块和现场设备之间的接线可使用三种连接方式：CP451-50 CPU 处理器模块专用信号电缆连接、压力钳端子连接和 MIL 电缆连接。CP451-50 对于专用信号电缆连接，专用信号电缆用于通过端子板或继电器板连接现场设备。信号电缆接口适配器在结构上与CP451-50 I/O 模块集成在一起。通过分别选择 I/O 模块和信号电缆的选项代码，可以防止错误类型的 I/O 模块插入。至于压力钳端子连接，现场设备可以直接连接到 I/O 模块。横河Yokogawa CP451-50 I/O 模块有两种类型的压力钳接线端子可供选择——一种是单配置类型，另一种是双冗余配置类型。I/O 模块可以在端子块上实现双冗余。客户提供的 MIL 电缆可以直接连接到 I/O 模块，无需接线端子。为防止 MIL 电缆从 I/O 模块断开，电缆连接器盖(SCCC01 和 SCCC02)可与 MIL 电缆一起使用。
CP451-51
CP451-51
There are three connection methods available between the CP451-50 I/O module and field devices: dedicated signal cable connection for the CP451-50 CPU processor module, pressure clamp terminal connection, and MIL cable connection. CP451-50 is used for dedicated signal cable connections, which are used to connect field devices through terminal boards or relay boards. The signal cable interface adapter is structurally integrated with the CP451-50 I/O module. By selecting option codes for I/O modules and signal cables separately, it is possible to prevent incorrect types of I/O modules from being inserted. As for the pressure clamp terminal connection, on-site devices can be directly connected to the I/O module. Yokogawa CP451-50 I/O module has two types of pressure clamp terminal blocks to choose from – one is a single configuration type, and the other is a dual redundant configuration type. I/O modules can achieve dual redundancy on terminal blocks. The MIL cable provided by the customer can be directly connected to the I/O module without the need for wiring terminals. To prevent MIL cables from disconnecting from the I/O module, cable connector covers (SCCC01 and SCCC02) can be used with MIL cables.
CP451-51
CP451-51
专业销售世界各大电气品牌产品产品海外直接采购，正品库存，价格优惠售后保修，型号齐全，一样的产品，不一样的价格与服务。大量供应原装进口DCS系统配件，PLC系统配件。主营:ABB、GE发那科、Bentl本特利、Triconex英维思、Woodward伍德沃德、Foxboro福克斯波罗、Westinghouse西屋/Emerson艾默生、Reliance瑞恩、SchneiderModicon施耐德莫迪康、A-B、HIMA黑马、Motorola摩托罗拉、Kollmorgen科尔摩根Bosch/Rexroth/博世力上乐，NI,YOKOGAWA横河，等各大品牌的DCS系统配件，机器人系统配件，大型伺服系统停产备件。
CP451-51
