这个FBM是一个通 用的以太网硬件模块可以加载哪些不同的软件驱动程序。这些驱动程序配置FBM来识别特定的设备使用的协议。几个软件驱动程是标准产品。其他自定义可以开发驱动程序以满足特定需求。这些驱动程序被动态下载到用FBM232软件代码专门设计的接口与第三方设备的协议。的配置程序和软件每个驱动程序的要求都是独一无二的正在集成到系统中的设备。
以太网链路设置
FBM232与现场的数据通信设备通过位于上的RJ-45连接器前面的FBM232模块。的注册插孔- 45FBM232的连接器可以通过集线器，或通过以太网交换机到现场设备(参见“以太网集线器和”开关”(第8页)。 多重连接设备到FBM232需要集线器或交换机。
FBM232
配置器
FDSI配置器设置FBM232 XML基于端口和设备配置文件。港口配置器允许容易地设置每个端口的通信参数(例如，DHCP (Dynamic HostConfiguration Protocol)，IP地址)。 不需要设备配置器所有设备,但在需要时配置设备具体和点具体的考虑(例如，扫描速率,要传输的数据的地址,和一次要传输的数据量务)。
操作
FBM232可以访问多达64个设备读取或写数据。从I/A串联控制站到哪个FBM232连接,最多2000分布式控制接口(DCI)数据连接可以用来读或写数据。支持数据类型由加载的特定驱动程序决定在FBM232上,将数据转换为DCI
FBM232
This FBM is a universal Ethernet hardware module that can load different software drivers. These drivers configure FBM to identify the protocols used by specific devices. Several software drivers are standard products. Other customizations can develop drivers to meet specific needs. These drivers are dynamically downloaded to a protocol specifically designed interface with third-party devices using FBM232 software code. The configuration program and software requirements for each driver are unique to the devices being integrated into the system.
Ethernet link settings
The FBM232 communicates with the on-site data communication equipment through the FBM232 module located in front of the RJ-45 connector on the. The registered jack -45FBM232 connector can be connected to the field device through a hub or Ethernet switch (see “Ethernet Hub and Switch” on page 8). Multiple connection devices to FBM232 require a hub or switch.
FBM232
Configurator
The FDSI configurator sets the FBM232 XML based on port and device configuration files. The port configurator allows for easy setting of communication parameters for each port (such as DHCP (Dynamic HostConfiguration Protocol), IP address). No device configurator is required for all devices, but device specific and point specific considerations are configured when needed (such as scan rate, address of data to be transmitted, and primary data volume to be transmitted).
operation
FBM232 can access up to 64 devices to read or write data. From the I/A serial control station to which FBM232 connection, up to 2000 distributed control interface (DCI) data connections can be used to read or write data. Support data type determined by the specific driver loaded on FBM232, converting data to DCI
FBM232
