当晶体管基极为高电平时，晶体管饱和导通，等效电路如图3所示， 此时电感l储存能量，电容C充电。当晶体管基极为低电平时，晶体管截止，等效电路如图4所示,此时电感L释放能量，电容C放电。通常我们的PCB板上还有采样电路,反馈电路，以此来调节基极控制电压的占空比，来达到稳压的目的。同时，由于负载和晶体管串联，输出电压小于输入电压，所以又叫降压开关电路(buck开关电路) 。对应的并联开关电路原理相似，同时由于晶体管并联，电感产生的感应电动势与电压相叠加后作用于负载，所以输出电压会高于输入电压。
GDB021BE
GDB021BE
When the transistor base is at a high level, the transistor saturates and conducts, and the equivalent circuit is shown in Figure 3. At this time, the inductor l stores energy and the capacitor C charges. When the transistor base is low, the transistor is cut off, and the equivalent circuit is shown in Figure 4. At this time, the inductor L releases energy and the capacitor C discharges. Usually, our PCB board also has sampling circuits and feedback circuits to adjust the duty cycle of the base control voltage and achieve voltage stabilization. At the same time, due to the series connection between the load and the transistor, the output voltage is smaller than the input voltage, so it is also called a buck switch circuit. The principle of the corresponding parallel switch circuit is similar, and due to the parallel connection of transistors, the induced electromotive force generated by the inductance and voltage are combined to act on the load, so the output voltage will be higher than the input voltage.
GDB021BE
GDB021BE
专业销售世界各大电气品牌产品产品海外直接采购，正品库存，价格优惠售后保修，型号齐全，一样的产品，不一样的价格与服务。大量供应原装进口DCS系统配件，PLC系统配件。主营:ABB、GE发那科、Bentl本特利、Triconex英维思、Woodward伍德沃德、Foxboro福克斯波罗、Westinghouse西屋/Emerson艾默生、Reliance瑞恩、SchneiderModicon施耐德莫迪康、A-B、HIMA黑马、Motorola摩托罗拉、Kollmorgen科尔摩根Bosch/Rexroth/博世力上乐，NI,YOKOGAWA横河，等各大品牌的DCS系统配件，机器人系统配件，大型伺服系统停产备件。
GDB021BE
