- 32 个模拟输出通道
- 0.8Ω 输出阻抗
- 随机更新（非扫描）
- 双缓冲输出的软件或外部同步更新
- 单基准电位计
- 通过复位或软件命令启动自动校准
- 单极性（0至+10V、0至+5V、0至+2.5V）或双极性（±2.5、±5和±10V）软件可选
- 自检
- 前面板状态指示灯
- 前面板模拟输出连接器
- 前面板基准电压访问
VMIVME-4140 模拟输出板提供 32 个具有 12 位分辨率的高质量模拟输出通道，可在 ±10 V 时提供或吸收 10 mA 电流。每个输出都分配有一个专用的D/A转换器（DAC）。模拟输出可以与现场接线断开，以便进行离线测试。校准和自检由 VMEbus 系统复位或软件命令的执行启动。在校准期间，将编制偏移和增益系数表并将其存储在RAM中。有一个失调和增益条目对应于在六个输出电压范围内配置的32个通道中的每一个。
VMIVME-4140
VMIVME-4140
Features:
32 analog output channels
0.8 Ω output impedance
Random update (non scanning)
Software or external synchronous updates for dual buffered outputs
Single reference potentiometer
Initiate automatic calibration through reset or software commands
Unipolar (0 to+10V, 0 to+5V, 0 to+2.5V) or bipolar (± 2.5, ± 5, and ± 10V) software options
Self inspection
Front panel status indicator light
Front panel analog output connector
Front panel reference voltage access
The VMIVME-4140 analog output board provides 32 high-quality analog output channels with 12 bit resolution, which can provide or absorb 10 mA current at ± 10 V. Each output is assigned a dedicated D/A converter (DAC). The analog output can be disconnected from the on-site wiring for offline testing. Calibration and self check are initiated by VMEbus system reset or software command execution. During calibration, offset and gain coefficient tables will be compiled and stored in RAM. There is an offset and gain entry corresponding to each of the 32 channels configured within the six output voltage ranges.
VMIVME-4140
VMIVME-4140
