GE IC670ALG310模块是一种电压源模拟输出模块。它设计有 8 个不同的电压输出通道，可以根据操作员的配置自动缩放。该模块从与其连接的总线接口单元获取输入，增强数据以进行校准，并将数据转换为 -10 至 +10 V 范围内的输出电压。IC670ALG310输出模块具有增强的诊断功能。它可以轻松检测超量程和下量程情况、用户功率损失和未校准模块。输出模块还具有警报功能，用户可以针对不同的事件设置警报。当输出值不满足模块最大或最小输出设置的 50 毫伏要求时，模块会将输出值视为超出范围和超范围。
IC670ALG310
IC670ALG310输出模块尺寸紧凑，可以安装在狭小的空间内。对于输入数据，需要0到8个字的模拟输出数据，0到3个字节的输入数据用于模块和通道状态，0到2字节的输出数据用于清除报警。所有数据交换都在输出模块和总线接口单元之间进行。IC670ALG310输出模块具有“通道活动”功能，允许操作员将单个通道配置为活动或非活动。该模块还具有本地输出默认功能，有助于将数据配置为默认设置或总线接口单元中模块数据的零。该模块从总线接口吸收 170 毫安的电流。模块的分辨率为14位，幅度数据大小为14位。
IC670ALG310
The GE IC670ALG310 module is a voltage source analog output module. It is designed with 8 different voltage output channels that can be automatically scaled according to the operator’s configuration. This module obtains input from the bus interface unit connected to it, enhances data for calibration, and converts the data into an output voltage within the range of -10 to+10 V. The IC670ALG310 output module has enhanced diagnostic functions. It can easily detect out of range and down range situations, user power loss, and uncalibrated modules. The output module also has an alarm function, allowing users to set alarms for different events. When the output value does not meet the module’s maximum or minimum output setting of 50 millivolts, the module will consider the output value as out of range and out of range.
IC670ALG310
The IC670ALG310 output module has a compact size and can be installed in a narrow space. For input data, analog output data of 0 to 8 words is required, input data of 0 to 3 bytes is used for module and channel status, and output data of 0 to 2 bytes is used to clear alarms. All data exchange takes place between the output module and the bus interface unit. The IC670ALG310 output module has a “channel active” function, allowing the operator to configure a single channel as active or inactive. This module also has a local output default function, which helps to configure data to default settings or zero module data in the bus interface unit. This module absorbs a current of 170 milliamperes from the bus interface. The resolution of the module is 14 bits, and the amplitude data size is 14 bits.
IC670ALG310
