IC697CPM790是GE FANUC制造的64 MHz CPU，具有使用32位浮点和微处理器80486DX2的计算能力。该CPU利用单插槽编程软件，该软件与Windows或MS-DOS配合使用以执行配置和编程。
IC697CPM790包括高达 12K 的离散输入和输出（仅限混合单工模式）。 它具有专用于操作系统固件的闪存，允许通过PC和模块串行端口之间的连接进行固件更新。 用户使用编程软件或使用 RUN/STOP 三位置开关通过操作模式控制模块操作。内存保护密钥或软件密码可锁定配置和程序数据。
IC697CPM790-GD
IC697CPM790有四个绿色 LED，指示 CPU 的状态。空气冷却需要风扇组件。用户可以将总线发送器模块IC697BEM713连接到编程器以进行并行接口。带有 15 个引脚的 D 型连接器连接串行端口，该端口与 RS-485 兼容。在实际操作和上电期间，CPU 验证机架配置，同时其报警功能报告编程和/或实际配置中的任何偏差。IC697CPM790有一个锂电池，可以维持日历时钟操作、数据存储器和程序存储器。
需要注意的是，模块IC697CPM790必须与独立 C 程序一起使用，该程序提供三重模块化冗余 （TMR） 操作和自动测试例程。 除非此程序包含在加载的应用程序中，否则它将无法运行。
支持的选件模块如下：IC697 LAN接口模块、可编程协处理器、字母数字显示协处理器、IC660/661 I/O产品的总线控制器、通信模块、I/O链路接口以及IC697系列分立和模拟I/O模块。
IC697CPM790-GD
IC697CPM790 is a 64 MHz CPU manufactured by GE FANUC, with computing power using 32-bit floating-point and microprocessor 80486DX2. This CPU utilizes single slot programming software, which is used in conjunction with Windows or MS-DOS to perform configuration and programming.
IC697CPM790 includes up to 12K discrete inputs and outputs (mixed simplex mode only). It has flash memory dedicated to operating system firmware, allowing firmware updates to be made through connections between the PC and module serial ports. Users use programming software or use the RUN/STOP three-position switch to control the module operation through the operating mode. Memory protection keys or software passwords can lock configuration and program data.
IC697CPM790-GD
IC697CPM790 has four green LEDs that indicate the status of the CPU. Air cooling requires fan components. Users can connect the bus transmitter module IC697BEM713 to the programmer for parallel interface. A D-type connector with 15 pins connects to a serial port, which is compatible with RS-485. During actual operation and power on, the CPU verifies the rack configuration, and its alarm function reports any deviations in programming and/or actual configuration. IC697CPM790 has a lithium battery that can maintain calendar clock operation, data storage, and program storage.
It should be noted that module IC697CPM790 must be used in conjunction with a standalone C program that provides Triple Modular Redundancy (TMR) operation and automatic testing routines. Unless this program is included in the loaded application, it will not run.
The supported optional modules are as follows: IC697 LAN interface module, programmable coprocessor, alphanumeric display coprocessor, bus controller for IC660/661 I/O products, communication module, I/O link interface, and IC697 series discrete and analog I/O modules.
IC697CPM790-GD
