IC697MDL653是一个正/负逻辑输入模块，有32个点。该 24 VDC 模块由 GE 为 90-70 系列制造。 它的 32 个输入点排列在由 <> 个点组成的四个独立集合中。该IC697MDL653的其他特性包括正/负逻辑和接近开关兼容性、可选输入滤波器以及配置为中断的单个输入。这些功能在所有IC697 PLC中都很常见。但是，当IC697MDL653与其他类型的PLC耦合时，这些功能可能不适用。IC697MDL653模块的面板上还配备了LED指示灯，以提醒用户模块的状态。这些 LED 指示电路 PLC 侧每个点的开/关状态。
IC697MDL653
方便的是，用户无需使用跳线或DIP开关即可轻松配置模块的输入/输出参考。IC697MDL653设计为具有正逻辑和负逻辑特性;因此，它能够将电流从输入设备提供给普通用户。适用的输入设备连接到电源总线和模块输入。以下输入设备均与IC697MDL653兼容：按钮、限位开关、选择开关和电子接近开关，包括 2 线和 3 线类型。
理想情况下，该模块上的输入由任何IC697 PLC电压兼容输出模块驱动。输入电路提供足够的电流，以确保器件可靠运行。输入电流在ON状态下典型值为10mA，在不导通状态下在OFF状态下可以接受2 mA漏电流
IC697MDL653
IC697MDL653 is a positive/negative logic input module with 32 points. The 24 VDC module is manufactured by GE for the 90-70 series. Its 32 input points are arranged in four independent sets composed of<>points. Other features of the IC697MDL653 include positive/negative logic and proximity switch compatibility, optional input filters, and a single input configured as an interrupt. These functions are common in all IC697 PLCs. However, when IC697MDL653 is coupled with other types of PLCs, these functions may not be applicable. The panel of the IC697MDL653 module is also equipped with LED indicators to remind users of the module’s status. These LEDs indicate the on/off status of each point on the PLC side of the circuit.
IC697MDL653
Conveniently, users can easily configure the input/output reference of the module without using jumpers or DIP switches. IC697MDL653 is designed with positive and negative logic characteristics; Therefore, it can provide current from the input device to ordinary users. Suitable input devices are connected to the power bus and module inputs. The following input devices are all compatible with IC697MDL653: buttons, limit switches, selector switches, and electronic proximity switches, including 2-wire and 3-wire types.
Ideally, the inputs on this module are driven by any IC697 PLC voltage compatible output module. The input circuit provides sufficient current to ensure the reliable operation of the device. The typical value of the input current in the ON state is 10mA, and it can accept a leakage current of 2 mA in the OFF state without conduction
IC697MDL653
