该IS200VCMIH2BEE由通用电气设计，作为其工业燃气和蒸汽轮机控制系统Speedtronic Mark VI的一部分。 此版本的 Speedtronic 系统通常用于加工厂和发电应用，以控制涡轮机启动期间的速度、同步发电机、提供涡轮机负载控制以及防止负载损失和涡轮机超速情况。
该IS200VCMIH2BEE是单位数据高速公路（UDH）的一部分。它用作主通信控制器板。数据通过光纤以太网 （IONet） 读取并传输到其他电路板。
VCMI 板可设计用于单工或 TMR（三重模块化冗余）应用。单工板有一个 IONet 端口，而 TMR 板有三个。IS200VCMIH2BEE板是TMR板。
IS200VCMIH2BEE使用 SIFT 投票（软件实现的容错）。数据在一个数据包中广播到所有远程机架。这些远程位置的 VCMI 板提取相应的数据包数据。
IS200VCMIH2BEE是双面板。 电路板的背面主要装有电阻器和电容器。电路板的正面更为复杂，包括连接器端口（包括两个背板）、电感器/扼流圈、tp 测试点和集成电路。连接的前面板有三个 IONet 端口以及一个公串行端口。它有一个复位按钮、两个固定螺钉和四组 LED 指示灯（一组 3、一组 6、一组 8 和另一组 3）。面板上还标有公司徽标和董事会编号。
IS200VCMIH2BEE
IS200VCMIH2BEE
The IS200VCMIH2BEE is designed by General Electric as part of its industrial gas and steam turbine control system Speedtronic Mark VI. This version of the Speedtronic system is typically used in processing plants and power generation applications to control the speed during turbine start-up, synchronize the generator, provide turbine load control, and prevent load loss and turbine overspeed situations.
The IS200VCMIH2BEE is part of the Unit Data Highway (UDH). It serves as the main communication controller board. The data is read and transmitted to other circuit boards through fiber optic Ethernet (IONet).
The VCMI board can be designed for simplex or TMR (Triple Modular Redundancy) applications. The simplex board has one IONet port, while the TMR board has three. The IS200VCMIH2BEE board is a TMR board.
IS200VCMIH2BEE uses SIFT voting (software implemented fault tolerance). The data is broadcasted to all remote racks in one packet. The VCMI boards at these remote locations extract corresponding packet data.
IS200VCMIH2BEE is a double-sided board. The back of the circuit board is mainly equipped with resistors and capacitors. The front of the circuit board is more complex, including connector ports (including two backplanes), inductors/chokes, TP test points, and integrated circuits. The front panel connected has three IONet ports and one public serial port. It has a reset button, two fixing screws, and four sets of LED indicator lights (one set of 3, one set of 6, one set of 8, and another set of 3). The panel is also marked with the company logo and board number.
IS200VCMIH2BEE
IS200VCMIH2BEE
