IS215UCVGH1A是GE为Mark VI系统创建的带有面板的电路板组件。MKVI是通用电气作为Speedtronic系列的一部分发布的蒸汽和燃气轮机管理系统。 Speedtronic系列始于1969年，一直持续到1990年代Mark VI / Mark VIe发布。
MKVI存在五个版本的UCV控制器。IS215UCVGH1A是控制器的单插槽版本。任何以前的控制器都可以由IS215UCVGH1A直接替换。如果主板更换了早期版本的控制器，则不需要背板升级。IS215UCVGH1A将安装到 VME 机架中。
该IS215UCVGH1A采用英特尔的超低压赛扬650处理器芯片制造。该芯片具有128MB的SDRAM和128 MB的闪存。该板有一个前面板。面板有一个复位开关，后跟一个 SVGA 监视器端口。有一个键盘/鼠标端口和两个COM端口（并排，标记为1和2。该板有两个堆叠在一起的以太网端口。它们标记为 LAN1 和 LAN2。有两个独立的 USB 连接器、四个 LED 指示灯和一个面板开口。
IS215UCVGH1A板由多个辅助板填充。在某些地方设有支架，以接受辅助设备（如果添加）。该板只有一个背板。电路板表面有电容器、电感线圈、晶体振荡器、振荡芯片、跳线开关和集成电路。
IS215UCVGH1A
IS215UCVGH1A
IS215UCVGH1A is a circuit board component with panels created by GE for the Mark VI system. MKVI is a steam and gas turbine management system released by General Electric as part of the Speedtronic series. The Speedtronic series began in 1969 and continued until the release of the Mark VI/Mark VIe in the 1990s.
MKVI has five versions of UCV controllers. IS215UCVGH1A is the single slot version of the controller. Any previous controller can be directly replaced by IS215UCVGH1A. If the motherboard is replaced with an earlier version of the controller, there is no need for a backplane upgrade. IS215UCVGH1A will be installed in the VME rack.
The IS215UCVGH1A is manufactured using Intel’s ultra-low voltage Celeron 650 processor chip. The chip has 128MB of SDRAM and 128 MB of flash memory. This board has a front panel. The panel has a reset switch followed by an SVGA monitor port. There is one keyboard/mouse port and two COM ports (side by side, labeled 1 and 2). The board has two stacked Ethernet ports, labeled LAN1 and LAN2. It has two independent USB connectors, four LED indicators, and a panel opening.
The IS215UCVGH1A board is filled with multiple auxiliary boards. There are brackets in some places to receive auxiliary equipment (if added). This board only has one backplane. The surface of the circuit board includes capacitors, inductor coils, crystal oscillators, oscillation chips, jumper switches, and integrated circuits.
IS215UCVGH1A
IS215UCVGH1A
专业销售世界各大电气品牌产品产品海外直接采购，正品库存，价格优惠售后保修，型号齐全，一样的产品，不一样的价格与服务。大量供应原装进口DCS系统配件，PLC系统配件。主营:ABB、GE发那科、Bentl本特利、Triconex英维思、Woodward伍德沃德、Foxboro福克斯波罗、Westinghouse西屋/Emerson艾默生、Reliance瑞恩、SchneiderModicon施耐德莫迪康、A-B、HIMA黑马、Motorola摩托罗拉、Kollmorgen科尔摩根Bosch/Rexroth/博世力上乐，NI,YOKOGAWA横河，等各大品牌的DCS系统配件，机器人系统配件，大型伺服系统停产备件。
IS215UCVGH1A
