GE IS220PDIAH1A 离散输入模块

标记为离散I/O包的IS220PDIAH1A型号也与YDIA离散输入模块一起用于Mark VI系列。PDIA 型号可以使用几种不同的相关端子板，其中包括以下内容：

IS200TBCIH4C
IS200STCIH1A
IS200STCIH8A
IS200TBCIH2C
IS200TCIH2A

这些型号都与PDIA配合使用，被批准用于危险场所。在危险环境中使用时，需要特定的认证。认证ULE207685用于无害的 I 类 2 区 IIC 组和 I 类 2 类组 A、B、C 和 D 地点。在 ATEX 2 区 IIC 地点使用时需要特定的认证，认证为 UL DEMKO 12 ATEX 1114875X。

与Mark VI系列中的其他型号相比，IS220PDIAH1A不一定具有特定的面板，因为它是I / O包。在设备的正面，有七个指示灯，在电池组的右侧，在三个指示灯中，有电源指示灯和两个链路指示灯，一个指示为 ENet1，另一个指示为 ENet2。在这三个指示器下方，有一个以太网端口，用于将模型连接到以太网，以便于以太网通信。

IS220PDIAH1A包装具有两个位置标准，其中两个是 UL 600790 第 5 版和 UL 60079-15 第 3 版，用于 I 类 2 区 IIC 组。此信息可以在GEH-6725 Mark VI控制设备Hazloc手册中找到，该手册位于上面的手册选项卡下。

IS220PDIAH1A

The IS220PDIAH1A model labeled as a discrete I/O package is also used with the YDIA discrete input module for the Mark VI series. The PDIA model can use several different related terminal boards, including the following:
IS200TBCIH4C
IS200STCIH1A
IS200STCIH8A
IS200TBCIH2C
IS200TCIH2A
These models are used in conjunction with PDIA and are approved for use in hazardous locations. When used in hazardous environments, specific certifications are required. ULE207685 is certified for use in harmless Class I, Division 2, Group IIC, and Class I, Division 2, Groups A, B, C, and D. Specific certification is required for use at ATEX Zone 2 IIC locations, UL DEMKO 12 ATEX 1114875X.

IS220PDIAH1A

Compared to other models in the Mark VI series, the IS220PDIAH1A does not necessarily have a specific panel as it is an I/O package. On the front of the device, there are seven indicator lights. On the right side of the battery pack, among the three indicator lights, there are power indicator lights and two link indicator lights, one indicating ENet1 and the other indicating ENet2. Below these three indicators, there is an Ethernet port used to connect the model to Ethernet for Ethernet communication.
The IS220PDIAH1A packaging has two positional standards, two of which are UL 600790 5th edition and UL 60079-15 3rd edition, for Class I, Zone 2, Group IIC. This information can be found in the GEH-6725 Mark VI Control Equipment Hazloc manual, which is located under the manual tab above.
