MVI56-BAS是由Prosoft Technology制造的基本通信模块。它是一个单槽模块， 用于将1747-BAS和1771-DB模块 上使用的传统BASIC程序的大型安装基础转换为ControlL ogix系统。它的用户界面由三个端口组成一DH-485、 PRT1和PRT2。 这些端口用于进行通信、基本程序传输、ASCI通信、编程或DF1通信。MV156- BAS有一个小型闪存 盘插槽。你可以用CF卡存储基本程序。这些BASIC程序也可以导出到另-台或本地PC上。该设备有24065字节的可用内存。
MVI56-BAS
可通过该通信模块操作的主要功能是创建基本程序，以允许与ControlL ogix处理器进行数据传输，以及为特殊应用创建外部设备接口。该模块还可用于将使用ASCI编码的设备连接到ControlLogix背板。打印机、条形码阅读器或调制解调器就是这种情况。MVI56- BAS可以配置为DF1半双工I从机或DF1全双工模块。为了在这个模块和处理器之间传输数据，程序员必须使用梯形逻辑。样本梯形文件随设备一起交付。 该设备可以在0到60摄氏度(32到140华氏度)的温度下工作。它有四个LED状态指示器，分别用于模块操作、背板传输、应用和串行活动。要设置该模块,您需要RockwellAutomation RSLogix 5000编程软件(版本2.51或更高。
MVI56-BAS
MVI56-BAS is a basic communication module manufactured by Prosoft Technology. It is a single slot module used to convert the large installation foundation of traditional BASIC programs used on the 1747-BAS and 1771-DB modules into a ControlL ogix system. Its user interface consists of three ports – DH-485, PRT1, and PRT2. These ports are used for communication, basic program transmission, ASCI communication, programming, or DF1 communication. The MV156 BAS has a small flash drive slot. You can use a CF card to store basic programs. These BASIC programs can also be exported to another or local PC. This device has 24065 bytes of available memory.
MVI56-BAS
The main function that can be operated through this communication module is to create basic programs to allow data transmission with the ControlL ogix processor, as well as to create external device interfaces for special applications. This module can also be used to connect devices using ASCI encoding to the ControlLogix backplane. This is the case with printers, barcode readers, or modems. MVI56 BAS can be configured as a DF1 half duplex I slave or a DF1 full duplex module. In order to transfer data between this module and the processor, programmers must use ladder logic. The sample ladder file is delivered with the device. The device can operate at temperatures ranging from 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit). It has four LED status indicators for module operation, backplane transmission, application, and serial activity. To set up this module, you need RockwellAutomation RSLogix 5000 programming software (version 2.51 or higher).
