ProSoft MVI56E-SIE 以太网通信模块

ProSoft Technology的MVI56E- SIE模块是西[ ]子I业以太网客户端通信模块，专为ControlLogix系统设计。它允许ControlLogix PACs(可编程自动化控制器)作为以太网客户端与多达20个西]子S7-200、S7 -300、S7-400、 S7-1200和S7-1500 PLC接口，这些PLC作为以太网服务器工作。该模块通过了RoHS、CE和IECEx标准认证。 MVI56E-SIE模块附带以下组件:-根5英尺以太网电缆(直通配置)和一张包含模块配置I具的ProSoftsolutions CD或ProSoft solutions DVD。MVI56E-SIE模块使用ProSoft配置生成器，通过图形配置工具管理配置文件,还允许查看模块诊断信息。

MVI56E-SIE

MVI56E-SIE模块是一个单槽1756 ControlLogix背板兼容。该模块的电流负载在5伏DC下为800安,在23伏DC下为3安。该模块支持带自动交叉检测的10/100 Mbps以太网。以太网接口是RJ-45接口，带有用于链路和活动的LED指示灯。模块上的4字符字母数字LED显示屏可用于显示状态和诊断信息。模块上还提供了LED指示灯，用于显示电池状态、应用状态和模块状态。MVI56E-SIE模块的I工作温度范围为32至140华氏度,存储温度范围为-40至185华氏度。从10赫兹到150赫兹，模块的振动等级为5 G。操作冲击等级为30 G。

MVI56E-SIE

The MVI56E SIE module of ProSoft Technology is an Ethernet client communication module designed specifically for ControlLogix systems. It allows ControlLogix PACs (programmable automation controllers) as Ethernet clients to interface with up to 20 sub PLCs S7-200, S7-300, S7-400, S7-1200, and S7-1500, which operate as Ethernet servers. This module has been certified to RoHS, CE, and IECEx standards. The MVI56E-SIE module comes with the following components: a 5-foot Ethernet cable (straight through configuration) and a ProSoftsolutions CD or ProSoft solutions DVD containing the module configuration I. The MVI56E-SIE module uses the ProSoft configuration generator, manages configuration files through graphical configuration tools, and also allows viewing module diagnostic information.

MVI56E-SIE

The MVI56E-SIE module is a single slot 1756 ControlLogix backplane compatible. The current load of this module is 800 A at 5 V DC and 3 A at 23 V DC. This module supports 10/100 Mbps Ethernet with automatic cross detection. The Ethernet interface is an RJ-45 interface with LED indicators for links and activities. The 4-character alphanumeric LED display screen on the module can be used to display status and diagnostic information. LED indicator lights are also provided on the module to display battery status, application status, and module status. The I operating temperature range of the MVI56E-SIE module is 32 to 140 degrees Fahrenheit, and the storage temperature range is -40 to 185 degrees Fahrenheit. The vibration level of the module is 5 G from 10 Hz to 150 Hz. The operating impact level is 30 G.
