用于 CompactLogix™ 系列控制器的 MVI69E-MBTCP Modbus TCP/IP 模块专为需要 Modbus TCP 连接的所有应用而设计。该模块带有附加配置文件和附加说明，以减少调试时间。MVI69E-MBTCP 具有一个以太网端口，用于诊断和应用数据。该模块支持客户端和服务器连接，以使用 Modbus 协议与各种设备进行接口。
MVI69E-MBTCP
The inRAx Modbus TCP/IP Communication Module is designed to allow CompactLogix® /MicroLogix® processors to interface with other Modbus TCP/IP protocol-compatible devices, including not only Modicon® processors, but also a wide variety of other Client and server devices.
The MVI69-MNET module is a single-slot solution that provides a powerful connection between Rockwell Automation® CompactLogix processors and Modbus TCP/IP network applications. The Modbus TCP/IP network applications include those networks hosted by Modicon Quantum processors, networks controlled by operator interface software applications, and the growing number of manufactured devices that support this protocol.
The module acts as an input/output module between the Modbus TCP/IP network and the CompactLogix backplane. The data transfer from the processor is asynchronous from the actions on the Modbus TCP/IP network. A 5000 16-bit register data space in the module exchanges data between the processor and the Modbus TCP/IP network.
MVI69E-MBTCP
特性 优势
- Support for the storage and transfer of up to 5000 registers to/from the PLC processor using the block transfer interface
- User-definable module memory usage
- 10/100 Base-T Ethernet-compatible interface
- All data mapping begins at Modbus register 40001
- Configurable parameters for the Client, including a minimum response delay of 0 to 65535 milliseconds
- Floating-point support for Enron, Daniels®, and other floating-point data types
- Single-Slot, 1769 backplane-compatible
- The module is recognized as an Input/Output module and has access to processor memory for data transfer between processor and module.
- Ladder Logic is used for data transfer between module and processor. Sample ladder file included.
- Configuration data obtained from configuration text file downloaded to module. Sample configuration file included.
- Supports all CompactLogix and MicroLogix 1500 LRP Controllers except 1769-QBFC1B, 1769-L16x, and 1769-L18x.
MVI69E-MBTCP
inRAx Modbus TCP/IP通信模块旨在允许CompactLogix®/MicroLogix®处理器与其他Modbus TCP/IP协议兼容设备接口，不仅包括Modicon®处理器，还包括各种其他客户端和服务器设备。
MVI69-MNET模块是一种单插槽解决方案，可在Rockwell Automation®CompactLogix处理器和Modbus TCP/IP网络应用程序之间提供强大的连接。Modbus TCP/IP网络应用程序包括由Modicon Quantum处理器托管的网络、由操作员接口软件应用程序控制的网络，以及越来越多支持该协议的制造设备。
该模块充当Modbus TCP/IP网络和CompactLogix背板之间的输入/输出模块。来自处理器的数据传输与Modbus TCP/IP网络上的操作异步。模块中的5000 16位寄存器数据空间在处理器和Modbus TC之间交换数据
